Texas Instruments TL072CPWRG4

Part No.:: TL072CPWRG4

Manufacturer:: Texas Instruments

Package:: 8-TSSOP (0.173, 4.40mm Width)

Datasheet:: TL072CPWRG4.pdf

Description:: IC OPAMP JFET 2 CIRCUIT 8TSSOP

In Stock:: 2178

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

TL072CPWRG4 Specifications

Package/Case:
8-TSSOP (0.173, 4.40mm Width)
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Discontinued at Mosen
AmplifierType:
J-FET
NumberofCircuits:
2
OutputType:
-
SlewRate:
13V/µs
GainBandwidthProduct:
3 MHz
-3dbBandwidth:
-
Current-InputBias:
65 pA
Voltage-InputOffset:
3 mV
Current-Supply:
1.4mA (x2 Channels)
Current-Output/Channel:
-
Voltage-SupplySpan(Min):
10 V
Voltage-SupplySpan(Max):
30 V
OperatingTemperature:
0°C ~ 70°C (TA)
MountingType:
Surface Mount

TL072CPWRG4 this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including TL072CPWRG4 price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for TL072CPWRG4 to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

TL072CPWRG4 information

Views：

TL072CPWRG4 Typical application Circuitry

TL072CPWRG4

The TL072CPWRG4 is a dual low-noise JFET-input operational amplifier (op-amp), widely used in applications requiring good noise performance, high input impedance, and low power consumption.

TL072CPWRG4 Application Scenarios

- Audio Processing: Suitable for use in audio mixers, guitar pedals, and preamplifiers.

- Active Filtering: Commonly employed in designing active filters for audio or communication systems.

- Sensor Amplification: Ideal for amplifying low-level signals from sensors.

- Voltage Follower: Utilized in impedance matching and signal isolation.

TL072CPWRG4 Key Features

- Dual Op-Amp Configuration: Contains two operational amplifiers in a single package.

- Low Noise Operation: Beneficial for high-fidelity audio applications.

- High Input Impedance: Ideal for handling signals from high-impedance sources.

- Low Power Consumption: Suitable for battery-operated devices.

- Wide Bandwidth and High Slew Rate: Enables the handling of fast signal variations.

Circuit Integration: Audio Pre-Amplifier

1. Connections for the power supply:

- VCC+ (Pin 8): Attach to the power supply's positive side, such as +15V.

- VCC- (Pin 4): Connect to the negative side of the power supply (e.g., -15V).

2. Input and Output Configuration:

- Non-Inverting Input (Pin 3 for Amp 1): Connect to the audio input source.

- Inverting Input (Pin 2 for Amp 1): Connect to the output through a feedback resistor to gain control.

- Output (Pin 1 for Amp 1): Connect to the next stage in the audio processing chain.

3. Feedback and Gain Control:

- Implement a resistor network between the output and inverting input for the desired gain setting.

Design-Related Issues of TL072CPWRG4

- Power Supply Quality: To reduce distortion and noise, make sure the power supply is reliable and clean.

- Component Selection: Use precision components in the feedback network for accurate gain control.

- Noise Suppression: Add bypass capacitors near the power supply pins to reduce electrical noise.

- Thermal Management: Take heat dissipation into account, especially for high-power uses.

- PCB Layout: Reduce signal path interference and noise coupling by designing the PCB.

The TL072CPWRG4, with its dual op-amp configuration, is highly suitable for audio applications requiring low noise and precise signal amplification. It is perfect for many analog processing applications because to its high input impedance and low power consumption. When designing circuits with this op-amp, focus on power supply stability, accurate component selection, noise reduction strategies, thermal considerations, and PCB layout optimization to achieve high-quality performance and reliability in the application.
