Name: TL071CDRG4
Brand: Texas Instruments
SKU: TL071CDRG4
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Texas Instruments TL071CDRG4

Part No.:: TL071CDRG4

Manufacturer:: Texas Instruments

Package:: 8-SOIC (0.154, 3.90mm Width)

Datasheet:: TL071CDRG4.pdf

Description:: IC OPAMP JFET 1 CIRCUIT 8SOIC

In Stock:: 2439

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

TL071CDRG4 Specifications

Package/Case:
8-SOIC (0.154, 3.90mm Width)
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Discontinued at Mosen
AmplifierType:
J-FET
NumberofCircuits:
1
OutputType:
-
SlewRate:
13V/µs
GainBandwidthProduct:
3 MHz
-3dbBandwidth:
-
Current-InputBias:
65 pA
Voltage-InputOffset:
3 mV
Current-Supply:
1.4mA
Current-Output/Channel:
-
Voltage-SupplySpan(Min):
10 V
Voltage-SupplySpan(Max):
30 V
OperatingTemperature:
0°C ~ 70°C
MountingType:
Surface Mount

TL071CDRG4 this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including TL071CDRG4 price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for TL071CDRG4 to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

TL071CDRG4 information

Views：

TL071CDRG4 Typical application Circuitry

TL071CDRG4

The TL071CDRG4 is a low noise, low power consumption, high input impedance operational amplifier, or op-amp. It's a versatile component widely used in various electronic circuits.

Functionality of TL071CDRG4

This op-amp is designed for applications where low noise and high-speed performance are required. It can be used for signal amplification, active filtering, and in a variety of analog processing circuits.

Application Scenarios of TL071CDRG4

1. Audio Equipment: Ideal for high-fidelity audio amplification due to its low noise characteristics.

2. Sensor Interface Circuits: Suitable for amplifying low-level signals from sensors.

3. Active Filters: Used in creating precise filtering circuits for signal processing.

4. Analog Signal Processing: Effective in various analog computing applications.

Parameter Characteristics of TL071CDRG4

- High Input Impedance: Prevents loading down the signal source.

- Low Noise Operation: Minimizes distortion in sensitive audio and measurement applications.

- Wide Frequency Bandwidth: Suitable for high-speed signal processing.

- Low Power Consumption: Efficient for battery-operated devices.

Application Example: Sensor Signal Amplification Circuit

1.Signal Input Configuration

- Non-Inverting Input: Connect the sensor output to pin 3 (non-inverting input) of the TL071CDRG4.

- Grounding: Attach pin 2 (inverting input) to ground using a resistor.

2.Gain Setting

- Feedback Loop: Connect pin 2 (inverting input) to pin 6 (output) with a resistor.

- Adjustable Gain: You can adjust the gain of the amplifier by changing the input resistor to feedback resistor ratio.

3.Power Supply Connections

- Positive Supply: Attach pin 7 to a source of positive voltage.

- Negative Supply: Connect pin 4 to ground for single-supply operations, or to a negative voltage source for dual-supply configurations.

4.Output Retrieval

- Amplified Signal Output: Obtain the amplified sensor signal from pin 6.

Design Considerations

1. Stable Power Supply: Ensure the power supply is stable to prevent noise and distortion in the amplified signal.

2. Effective Grounding: Implement proper grounding techniques to reduce interference.

3. Component Quality: To preserve signal integrity, use premium resistors and capacitors.

4. Heat Management: Consider the thermal aspects, especially if the op-amp is used in high-power applications.

In summary, the TL071CDRG4 is an effective op-amp for applications requiring low noise and high-speed performance, such as in sensor signal amplification. When designing circuits with this IC, focus on power supply stability, proper grounding, component quality, and thermal management to ensure efficient and reliable performance.
