Name: RHRG75120
Brand: ON Semiconductor
SKU: RHRG75120
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

ON Semiconductor RHRG75120

Part No.:: RHRG75120

Manufacturer:: ON Semiconductor

Package:: TO-247-2

Datasheet:: RHRG75120.pdf

Description:: DIODE GEN PURP 1200V 75A TO247-2

In Stock:: 481

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

RHRG75120 Specifications

Packaging:
Tube
Series:
RoHS:
RoHS
Speed:
Fast Recovery =< 500ns, > 200mA (Io)
Diode Type:
Standard
Part Status:
Active
Mounting Type:
Through Hole
Capacitance @ Vr, F:
-
Reverse Recovery Time (trr):
100 ns
Current - Reverse Leakage @ Vr:
250 µA @ 1200 V
Voltage - DC Reverse (Vr) (Max):
1200 V
Current - Average Rectified (Io):
75A
Operating Temperature - Junction:
-65°C ~ 175°C
Voltage - Forward (Vf) (Max) @ If:
3.2 V @ 75 A

RHRG75120 this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including RHRG75120 price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for RHRG75120 to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

RHRG75120 information

Views：

RHRG75120 Typical application Circuitry

RHRG75120

The RHRG75120 is a high-voltage, fast-recovery diode, typically used in power conversion and management applications. Its primary function is to manage high-voltage currents, making it suitable for use in power supplies, inverters, converters, and other high-voltage electronic systems. The diode's quick recovery times and capacity to withstand high voltage and current levels make it valuable.

Essential Elements of RHRG75120:

- High Voltage Tolerance: The RHRG75120 is capable of handling high voltages, making it suitable for power conversion in high-voltage systems.

- Quick Recovery Time: In switching applications, this diode's quick recovery time is essential for efficiency.

- High Current Capability: It can manage high levels of current, essential for high-power applications.

Situation of Application: Utilization in a Switching Power Source

In a switching power supply, the RHRG75120 can be used for rectification and managing high-voltage switching. Here's a detailed guide to integrating it:

- Rectification Stage:

- Connect the anode of the RHRG75120 to the AC input, which is to be rectified. This input can be from a transformer or another AC source.

- Connection to Load:

- The cathode should be connected to the load or the next stage in the power supply, such as a filtering capacitor or a voltage regulator.

- Heat Management:

- Given the high-power nature of the application, ensure proper heat dissipation for the RHRG75120. This may involve using heat sinks or thermal pads.

- Reverse Voltage Protection:

- In high-voltage applications, ensure that the reverse voltage does not exceed the specified limits of the RHRG75120 to prevent damage.

Design Considerations:

When designing a circuit with the RHRG75120, several factors need attention:

- Voltage and Current Ratings:

- Ensure that both the voltage and current ratings of the RHRG75120 are compatible with the application to prevent overstress and ensure reliability.

- Thermal Considerations:

- Managing heat is crucial, as high-power diodes like the RHRG75120 can generate significant heat during operation.

- Circuit Protection:

- Implement appropriate protection mechanisms, such as overvoltage and overcurrent protection, to safeguard the diode and the overall circuit.

- PCB Layout:

- The PCB layout should be designed to handle high currents and minimize trace resistance, which is especially important in power electronics.

Incorporating the RHRG75120 into a switching power supply involves careful consideration of voltage and current ratings, thermal management, circuit protection, and PCB design, to fully leverage the diode's capabilities in high-voltage and high-power applications.
