Nexperia USA Inc. PMEG6010CEJ,115

Part No.:: PMEG6010CEJ,115

Manufacturer:: Nexperia USA Inc.

Package:: SC-90, SOD-323F

Datasheet:: PMEG6010CEJ,115.pdf

Description:: DIODE SCHOTTKY 60V 1A SOD323F

In Stock:: 2552

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

PMEG6010CEJ,115 Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
RoHS:
RoHS
Speed:
Fast Recovery =< 500ns, > 200mA (Io)
Diode Type:
Schottky
Part Status:
Active
Mounting Type:
Surface Mount
Capacitance @ Vr, F:
68pF @ 1V, 1MHz
Reverse Recovery Time (trr):
-
Current - Reverse Leakage @ Vr:
50 µA @ 60 V
Voltage - DC Reverse (Vr) (Max):
60 V
Current - Average Rectified (Io):
1A (DC)
Operating Temperature - Junction:
150°C (Max)
Voltage - Forward (Vf) (Max) @ If:
660 mV @ 1 A
