NXP USA Inc. PMBFJ177,215

Part No.:: PMBFJ177,215

Manufacturer:: NXP USA Inc.

Package:: TO-236-3, SC-59, SOT-23-3

Datasheet:: PMBFJ177,215.pdf

Description:: JFET P-CH 30V 0.3W SOT23

In Stock:: 3420

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

PMBFJ177,215 Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Obsolete
FETType:
P-Channel
Voltage-Breakdown(V(BR)GSS):
30 V
DraintoSourceVoltage(Vdss):
30 V
Current-Drain(Idss)@Vds(Vgs=0):
1.5 mA @ 15 V
CurrentDrain(Id)-Max:
-
Voltage-Cutoff(VGSoff)@Id:
800 mV @ 10 nA
InputCapacitance(Ciss)(Max)@Vds:
8pF @ 10V (VGS)
Resistance-RDS(On):
300 Ohms
Power-Max:
300 mW
OperatingTemperature:
150°C (TJ)
MountingType:
Surface Mount

PMBFJ177,215 this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including PMBFJ177,215 price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for PMBFJ177,215 to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

PMBFJ177,215 information

Views：

PMBFJ177,215 Typical application Circuitry

PMBFJ177,215

The PMBFJ177,215 is a P-channel junction field-effect transistor (JFET) from NXP Semiconductors, enclosed in a plastic microminiature SOT23 package. It's characterized by its symmetrical silicon structure and is specially designed for applications requiring analog switches, choppers, and commutators.

Key Applications of PMBFJ177,215

- Analog Switches: The PMBFJ177,215 is often used in circuits where analog signals need to be controlled, such as audio or signal routing applications.

- Choppers and Commutators: In power electronics, it can function to modulate or alter an input signal, playing a vital role in devices like DC converters.

Parameter Features of PMBFJ177,215

- Package: It comes in a small SOT23 package, which is suitable for surface-mounted technology (SMT).

- Interchangeable Drain and Source Connections: Offers flexibility in circuit design.

Circuit Connection Example: Analog Switch

In an analog switch application, consider the following for effective circuit connection with the PMBFJ177,215:

1. Source and Drain Interchangeability: Utilize the flexibility of interchangeable source and drain connections to simplify PCB layout.

2. Gate Connection: Connect the gate to the control signal. The voltage at the gate controls the on/off state of the switch.

3. Source and Drain Connections: Join the input signal with one end and the output with the other. The configuration depends on your specific circuit requirements.

4. Biasing: Ensure proper biasing of the gate to maintain the switch in the desired state (on or off).

5. Load and Input Signal: The characteristics of the connected load and input signal should match the JFET's specifications.

Design Considerations of PMBFJ177,215

- Thermal Management: Despite the fact that JFETs typically emit less heat, thermal considerations should still be made, particularly in small SMT designs.

- Signal Integrity: Maintain signal integrity, especially in high-frequency applications, by minimizing the length of connections and avoiding layout that can introduce unwanted capacitance or inductance.

- Safety and Compliance: Adhere to safety standards and ensure the design complies with regulatory requirements, especially when used in sensitive applications.

The PMBFJ177,215 is suitable for designs requiring a compact, efficient solution for controlling analog signals, providing reliability and versatility in various applications. For detailed technical specifications and application guidance, referring to the datasheets provided by NXP Semiconductors and Alldatasheet is recommended.
