Texas Instruments OPA2333AIDRG4

Part No.:: OPA2333AIDRG4

Manufacturer:: Texas Instruments

Package:: 8-SOIC (0.154, 3.90mm Width)

Datasheet:: OPA2333AIDRG4.pdf

Description:: IC OPAMP ZERO-DRIFT 2 CIRC 8SOIC

In Stock:: 3877

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

OPA2333AIDRG4 Specifications

Package/Case:
8-SOIC (0.154, 3.90mm Width)
Packaging:
Tape & Reel (TR)
Series:
Zero-Drift
ProductStatus:
Discontinued at Mosen
AmplifierType:
CMOS, Zero-Drift
NumberofCircuits:
2
OutputType:
Rail-to-Rail
SlewRate:
0.16V/µs
GainBandwidthProduct:
350 kHz
-3dbBandwidth:
-
Current-InputBias:
70 pA
Voltage-InputOffset:
2 µV
Current-Supply:
17µA (x2 Channels)
Current-Output/Channel:
5 mA
Voltage-SupplySpan(Min):
1.8 V
Voltage-SupplySpan(Max):
5.5 V
OperatingTemperature:
-40°C ~ 125°C
MountingType:
Surface Mount
