Texas Instruments OPA2180IDGKR

Part No.:: OPA2180IDGKR

Manufacturer:: Texas Instruments

Package:: 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)

Datasheet:: OPA2180IDGKR.pdf

Description:: IC OPAMP ZERO-DRIFT 2CIRC 8VSSOP

In Stock:: 2043

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

OPA2180IDGKR Specifications

Package/Case:
8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
Zero-Drift
ProductStatus:
Active
AmplifierType:
Zero-Drift
NumberofCircuits:
2
OutputType:
Rail-to-Rail
SlewRate:
0.8V/µs
GainBandwidthProduct:
2 MHz
-3dbBandwidth:
-
Current-InputBias:
250 pA
Voltage-InputOffset:
15 µV
Current-Supply:
450µA (x2 Channels)
Current-Output/Channel:
18 mA
Voltage-SupplySpan(Min):
4.5 V
Voltage-SupplySpan(Max):
36 V
OperatingTemperature:
-40°C ~ 105°C
MountingType:
Surface Mount

OPA2180IDGKR this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including OPA2180IDGKR price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for OPA2180IDGKR to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

OPA2180IDGKR information

Views：

OPA2180IDGKR Typical application Circuitry

OPA2180IDGKR

The OPA2180IDGKR is a low-power, high-precision operational amplifier from Texas Instruments that is widely used in analog circuits. Integrating the OPA2180IDGKR properly is crucial for optimal performance. An extensive tutorial on the ways to connect this IC is provided below.

1. Power Supply Wiring: First, connect the positive voltage supply to Pin 8 (V+) and the ground to Pin 4 (V-). For applications requiring dual supplies, Pin 4 will be connected to the negative supply.

2. Input Terminals: The OPA2180IDGKR features dual op-amps. For the first amplifier, the inverting input is at Pin 2 (-IN_A) and the non-inverting input is at Pin 3 (+IN_A). For the second amplifier, -IN_B and +IN_B are found at Pins 5 and 6, respectively.

3. Output Leads: The output terminals for the dual op-amps are OUT_A (Pin 1) and OUT_B (Pin 7). These pins should be linked to the next stage of your circuit, which may be an ADC, another amplifier, or a load.

4. Decoupling Capacitors: For enhanced stability, include 10 µF and 0.1 µF capacitors in parallel between Pin 8 (V+) and Pin 4 (V-). Place these capacitors as near to the OPA2180IDGKR as you can.

5. Feedback Network: Depending on your application-be it voltage amplification, filtering, or another use case-insert suitable resistors or capacitors between the output and input terminals to form a feedback loop.

6. Signal Isolation: If you need to isolate the OPA2180IDGKR from other components, employ isolation resistors on the output pins.

7. Grounding Techniques: For noise-sensitive applications, consider using a star grounding method to minimize noise and interference.

8. Input Protection: If your setup exposes the OPA2180IDGKR to potentially harmful voltage spikes, add input protection circuits such as diodes.

9. Circuit Test Points: Integrate test points near key connections like the power supply, input, and output pins for straightforward troubleshooting and testing.

10. Review and Test: Once everything is assembled, power up your circuit and monitor the OPA2180IDGKR's output to ensure that it's behaving as expected. Cross-reference this performance with the specifications and guidelines outlined in the OPA2180IDGKR datasheet.

By paying attention to these critical connection points, you ensure that the OPA2180IDGKR functions at peak performance in your circuitry. Make sure to always consult the datasheet of the OPA2180IDGKR for the most accurate and specific guidance on electrical and mechanical characteristics.
