Analog Devices Inc. OP4177ARZ

Part No.:: OP4177ARZ

Manufacturer:: Analog Devices Inc.

Package:: 14-SOIC (0.154, 3.90mm Width)

Datasheet:: OP4177ARZ.pdf

Description:: IC OPAMP GP 4 CIRCUIT 14SOIC

In Stock:: 528

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

OP4177ARZ Specifications

Package/Case:
14-SOIC (0.154, 3.90mm Width)
Packaging:
Tube
Series:
-
ProductStatus:
Active
AmplifierType:
General Purpose
NumberofCircuits:
4
OutputType:
-
SlewRate:
0.7V/µs
GainBandwidthProduct:
1.3 MHz
-3dbBandwidth:
-
Current-InputBias:
500 pA
Voltage-InputOffset:
15 µV
Current-Supply:
400µA (x4 Channels)
Current-Output/Channel:
10 mA
Voltage-SupplySpan(Min):
5 V
Voltage-SupplySpan(Max):
30 V
OperatingTemperature:
-40°C ~ 125°C
MountingType:
Surface Mount
