Analog Devices Inc. OP37GSZ-REEL7

Part No.:: OP37GSZ-REEL7

Manufacturer:: Analog Devices Inc.

Package:: 8-SOIC (0.154, 3.90mm Width)

Datasheet:: OP37GSZ-REEL7.pdf

Description:: IC OPAMP GP 1 CIRCUIT 8SOIC

In Stock:: 9212

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

OP37GSZ-REEL7 Specifications

Package/Case:
8-SOIC (0.154, 3.90mm Width)
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Active
AmplifierType:
General Purpose
NumberofCircuits:
1
OutputType:
-
SlewRate:
17V/µs
GainBandwidthProduct:
63 MHz
-3dbBandwidth:
-
Current-InputBias:
15 nA
Voltage-InputOffset:
30 µV
Current-Supply:
-
Current-Output/Channel:
-
Voltage-SupplySpan(Min):
8 V
Voltage-SupplySpan(Max):
36 V
OperatingTemperature:
-40°C ~ 85°C
MountingType:
Surface Mount
