Analog Devices Inc. OP284FSZ

Part No.:: OP284FSZ

Manufacturer:: Analog Devices Inc.

Package:: 8-SOIC (0.154, 3.90mm Width)

Datasheet:

Description:: IC OPAMP GP 2 CIRCUIT 8SOIC

In Stock:: 15123

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

OP284FSZ Specifications

Package/Case:
8-SOIC (0.154, 3.90mm Width)
Packaging:
Tube
Series:
-
ProductStatus:
Active
AmplifierType:
General Purpose
NumberofCircuits:
2
OutputType:
Rail-to-Rail
SlewRate:
4V/µs
GainBandwidthProduct:
4.25 MHz
-3dbBandwidth:
-
Current-InputBias:
80 nA
Voltage-InputOffset:
175 µV
Current-Supply:
-
Current-Output/Channel:
10 mA
Voltage-SupplySpan(Min):
3 V
Voltage-SupplySpan(Max):
36 V
OperatingTemperature:
-40°C ~ 125°C
MountingType:
Surface Mount

OP284FSZ this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including OP284FSZ price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for OP284FSZ to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

OP284FSZ information

Views：

OP284FSZ Typical application Circuitry

OP284FSZ

The OP284FSZ is a dual operational amplifier characterized by its rail-to-rail output swing, low noise, and wide bandwidth. Applications that need for effective signal amplification across a broad dynamic range will find it very useful.

Applications of OP284FSZ

1. Sensor Interfaces: Commonly used in sensor signal conditioning, particularly in temperature and pressure monitoring systems.

2. Battery-Powered Devices: Ideal for portable electronic devices due to its low power consumption and rail-to-rail output capabilities.

3. Active Filtering: Suitable for use in active filter circuits in audio and communication systems, benefiting from its wide bandwidth and low noise.

Key Features of OP284FSZ

1. Rail-to-Rail Output Swing: Ensures maximum dynamic range in systems with limited power supply voltages.

2. Low Noise Operation: Provides clear signal amplification, critical in sensitive applications.

3. Wide Bandwidth: Enables efficient processing of high-frequency signals.

Circuit Design Example: Sensor Signal Amplifier

Detailed Circuit Configuration Using OP284FSZ:

1. Sensor Input (Pins 2 and 5): Connect the sensor outputs to Pin 2 (inverting input of the first op-amp) and Pin 5 (inverting input of the second op-amp).

2. Gain Setting (Pins 1 and 7): Establish the gain for each op-amp by connecting resistors from the output pins (Pin 1 for the first op-amp, Pin 7 for the second op-amp) to their respective inverting input pins.

3. Power Supply (Pins 4 and 8): Attach a bipolar power supply, with Pin 4 as the negative supply and Pin 8 as the positive supply. Ensure the supply voltage is within the operating range of the OP284FSZ.

4. Output Signals (Pins 1 and 7): The amplified sensor signals are available at these output pins.

5. Bypass Capacitors (Near Pins 4 and 8): To reduce noise, locate decoupling capacitors in close proximity to the power supply pins.

Design Considerations with OP284FSZ

1. Power Supply Quality: Ensure a stable and clean power supply to maintain optimal performance of the OP284FSZ.

2. PCB Layout Design: Carefully plan the PCB layout to minimize noise and reduce parasitic effects, particularly important in precision signal processing.

3. Thermal Management: Use suitable heat dissipation, particularly in enclosed areas or when running at high power levels.

4. Component Selection: Use high-quality components, especially in the feedback network, to maintain the accuracy and stability of the amplifier.

5. Grounding Techniques: Proper grounding is crucial to minimize noise and potential interference, especially in sensitive sensor applications.

This example demonstrates the setup of a sensor signal amplifier using the OP284FSZ. The OP284FSZ's rail-to-rail output, low noise, and wide bandwidth make it highly suitable for applications requiring accurate and efficient signal amplification.
