Name: OP27AJGB
Brand: Texas Instruments
SKU: OP27AJGB
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Texas Instruments OP27AJGB

Part No.:: OP27AJGB

Manufacturer:: Texas Instruments

Package:: 8-CDIP (0.300, 7.62mm)

Datasheet:: OP27AJGB.pdf

Description:: IC OPAMP GP 1 CIRCUIT 8CDIP

In Stock:: 3211

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

OP27AJGB Specifications

Package/Case:
8-CDIP (0.300, 7.62mm)
Packaging:
Bulk
Series:
-
ProductStatus:
Active
AmplifierType:
General Purpose
NumberofCircuits:
1
OutputType:
-
SlewRate:
2.8V/µs
GainBandwidthProduct:
8 MHz
-3dbBandwidth:
-
Current-InputBias:
10 nA
Voltage-InputOffset:
10 µV
Current-Supply:
-
Current-Output/Channel:
30 mA
Voltage-SupplySpan(Min):
8 V
Voltage-SupplySpan(Max):
44 V
OperatingTemperature:
-55°C ~ 125°C
MountingType:
Through Hole
