Name: OP262GS
Brand: Analog Devices Inc.
SKU: OP262GS
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Analog Devices Inc. OP262GS

Part No.:: OP262GS

Manufacturer:: Analog Devices Inc.

Package:: 8-SOIC (0.154, 3.90mm Width)

Datasheet:: OP262GS.pdf

Description:: IC OPAMP GP 2 CIRCUIT 8SOIC

In Stock:: 2994

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

OP262GS Specifications

Package/Case:
8-SOIC (0.154, 3.90mm Width)
Packaging:
Tube,Tube
Series:
-
ProductStatus:
Obsolete
AmplifierType:
General Purpose
NumberofCircuits:
2
OutputType:
Rail-to-Rail
SlewRate:
13V/µs
GainBandwidthProduct:
15 MHz
-3dbBandwidth:
-
Current-InputBias:
260 nA
Voltage-InputOffset:
25 µV
Current-Supply:
550µA (x2 Channels)
Current-Output/Channel:
30 mA
Voltage-SupplySpan(Min):
2.7 V
Voltage-SupplySpan(Max):
12 V
OperatingTemperature:
-40°C ~ 125°C
MountingType:
Surface Mount

OP262GS this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including OP262GS price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for OP262GS to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

OP262GS information

Views：

OP262GS Typical application Circuitry

OP262GS

The OP262GS is a dual high-speed operational amplifier known for its robust performance in applications requiring fast slew rates and wide bandwidth. This op-amp is particularly suited for driving ADCs, video signal processing, and high-speed filtering applications. Its combination of speed and precision makes it versatile across a broad spectrum of industrial, communication, and consumer electronics applications.

Application Scenarios

- Driving ADCs: Ensuring minimal distortion and accurate signal representation for digital conversion.

- Video Processing: Amplifying and filtering video signals with high fidelity and speed.

- Active Filtering: Using fast filters to condition signals in data gathering systems.

Parameters and Features

- High Slew Rate: Enables the op-amp to respond quickly to input signal changes, making it ideal for high-speed applications.

- Broad Bandwidth: Enables processing of high-frequency communications while preserving signal integrity.

- Dual Configuration: This option optimizes circuit design space and cost by providing two operational amplifiers in a single package.

- Low Distortion: This feature guarantees clear signal amplification, which is crucial for audio and video applications.

Detailed Circuit Connection for Driving ADCs

Using the OP262GS to drive an Analog-to-Digital Converter (ADC) showcases its ability to handle fast signals with precision. The following steps detail the connection and configuration of the OP262GS in this application:

1. Power Supply Connections: The OP262GS requires a dual power supply for optimal performance. Attach pin 4 to the negative supply voltage and pin 8 to the positive supply voltage. To minimize noise and ensure stable operation, place decoupling capacitors, typically 0.1 µF, as close to these pins as possible.

2. Input Signal Conditioning: Connect the signal source to the non-inverting input (pin 3) of the first amplifier. A series resistor may be used to limit the current into the OP262GS and work with an input capacitor to form an input low-pass filter, if necessary, to condition the signal before amplification.

3. Feedback and Gain Setting: A feedback resistor (Rf) from the output (pin 1) to the inverting input (pin 2) sets the amplifier's gain. To configure the gain, a resistor (Rg) between pin 2 and ground controls the amplification factor according to the formula 1 + (Rf/Rg).

4. Output to ADC: The conditioned signal available at pin 1 is then directed to the ADC input. Given the OP262GS's high slew rate and bandwidth, it can drive the ADC effectively, ensuring that the analog signal is accurately represented in digital form.

5. Second Amplifier Utilization: The second operational amplifier within the OP262GS package (pins 5, 6, and 7 for the non-inverting input, inverting input, and output, respectively) can be used for additional signal processing tasks, such as further filtering or a second stage of amplification.

Design Considerations

When designing a circuit with the OP262GS for driving ADCs, several key aspects should be taken into account:

- Stability with Capacitive Loads: Ensure the circuit is stable when driving capacitive loads, such as an ADC input. It could be required to place a series isolation resistor between the ADC input and the op-amp output.

- Power Supply Noise: High-speed operations are sensitive to power supply noise. Employing a clean power supply and careful decoupling can mitigate potential issues.

- Thermal Considerations: The OP262GS can dissipate significant power, especially when driving heavy loads. Adequate cooling or heat sinking may be required to maintain optimal performance.

- Signal Integrity: To preserve the integrity of high-speed signals, keep signal paths short and use proper PCB layout techniques to minimize parasitic capacitance and inductance.

Incorporating the OP262GS in an application to drive ADCs leverages its high-speed capabilities, ensuring that the analog signal is accurately amplified and conditioned for digital conversion. This makes the OP262GS an excellent choice for precision applications requiring fast signal processing.
