Fairchild Semiconductor NCP301HSN27T1G

Part No.:: NCP301HSN27T1G

Manufacturer:: Fairchild Semiconductor

Package:: SOT-23-5 Thin, TSOT-23-5

Datasheet:: NCP301HSN27T1G.pdf

Description:: VOLTAGE DETECTOR SERIES WITH OPE

In Stock:: 2513

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

NCP301HSN27T1G Specifications

Packaging:
Bulk
Series:
-
ProductStatus:
Active
Type:
Simple Reset/Power-On Reset
NumberofVoltagesMonitored:
1
Voltage-Threshold:
2.7V
Output:
Open Drain or Open Collector
Reset:
Active High
ResetTimeout:
-
OperatingTemperature:
-40°C ~ 125°C (TA)
MountingType:
Surface Mount
