ON Semiconductor NB7VQ14MMNG

Part No.:: NB7VQ14MMNG

Manufacturer:: ON Semiconductor

Package:: 16-VFQFN Exposed Pad

Datasheet:: NB7VQ14MMNG.pdf

Description:: IC CLK BUFFER 1:4 8.5GHZ 16QFN

In Stock:: 123

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

NB7VQ14MMNG Specifications

Packaging:
Tube
Series:
GigaComm™
Product Status:
Active
Type:
Fanout Buffer (Distribution), Multiplexer
Number of Circuits:
1
Ratio-Input: Output:
1:4
Differential-Input: Output:
Yes/Yes
Input:
CML, LVDS, LVPECL
Output:
CML
Frequency-Max:
8.5 GHz
Voltage-Supply:
1.71V ~ 3.6V
Operating Temperature:
-40°C ~ 85°C
Mounting Type:
Surface Mount
