Analog Devices Inc. ADCLK944BCPZ-R2

Part No.:: ADCLK944BCPZ-R2

Manufacturer:: Analog Devices Inc.

Package:: 16-WFQFN Exposed Pad, CSP

Datasheet:: ADCLK944BCPZ-R2.pdf

Description:: IC CLK BUFFER 1:4 7GHZ 16LFCSP

In Stock:: 1660

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ADCLK944BCPZ-R2 Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
SiGe
Product Status:
Active
Type:
Fanout Buffer (Distribution)
Number of Circuits:
1
Ratio-Input: Output:
1:4
Differential-Input: Output:
Yes/Yes
Input:
CML, CMOS, LVDS, LVPECL
Output:
ECL, LVPECL
Frequency-Max:
7 GHz
Voltage-Supply:
2.375V ~ 3.63V
Operating Temperature:
-40°C ~ 85°C
Mounting Type:
Surface Mount
