Texas Instruments INA821IDGKR

Part No.:: INA821IDGKR

Manufacturer:: Texas Instruments

Package:: 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)

Datasheet:: INA821IDGKR.pdf

Description:: IC INST AMP 1 CIRCUIT 8VSSOP

In Stock:: 2246

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

INA821IDGKR Specifications

Package/Case:
8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Packaging:
Tape & Reel (TR)
Series:
-
ProductStatus:
Active
AmplifierType:
Instrumentation
NumberofCircuits:
1
OutputType:
-
SlewRate:
2V/µs
GainBandwidthProduct:
-
-3dbBandwidth:
4.7 MHz
Current-InputBias:
150 pA
Voltage-InputOffset:
45 µV
Current-Supply:
600µA
Current-Output/Channel:
20 mA
Voltage-SupplySpan(Min):
4.5 V
Voltage-SupplySpan(Max):
36 V
OperatingTemperature:
-40°C ~ 125°C (TA)
MountingType:
Surface Mount
