Texas Instruments INA2133UA/2K5G4

Part No.:: INA2133UA/2K5G4

Manufacturer:: Texas Instruments

Package:: 14-SOIC (0.154, 3.90mm Width)

Datasheet:: INA2133UA/2K5G4.pdf

Description:: IC OPAMP DIFF 1 CIRCUIT 14SOIC

In Stock:: 2134

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

INA2133UA/2K5G4 Specifications

Package/Case:
14-SOIC (0.154, 3.90mm Width)
Packaging:
Tape & Reel (TR)
Series:
-
ProductStatus:
Obsolete
AmplifierType:
Differential
NumberofCircuits:
1
OutputType:
-
SlewRate:
5V/µs
GainBandwidthProduct:
-
-3dbBandwidth:
1.5 MHz
Current-InputBias:
-
Voltage-InputOffset:
150 µV
Current-Supply:
950µA
Current-Output/Channel:
32 mA
Voltage-SupplySpan(Min):
4.5 V
Voltage-SupplySpan(Max):
36 V
OperatingTemperature:
-40°C ~ 85°C
MountingType:
Surface Mount
