Texas Instruments INA2132U

Part No.:: INA2132U

Manufacturer:: Texas Instruments

Package:: 14-SOIC (0.154, 3.90mm Width)

Datasheet:: INA2132U.pdf

Description:: IC INST AMP 1 CIRCUIT 14SOIC

In Stock:: 2798

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

INA2132U Specifications

Package/Case:
14-SOIC (0.154, 3.90mm Width)
Packaging:
Bulk,Tube
Series:
-
ProductStatus:
Active
AmplifierType:
Instrumentation
NumberofCircuits:
1
OutputType:
-
SlewRate:
0.1V/µs
GainBandwidthProduct:
-
-3dbBandwidth:
300 kHz
Current-InputBias:
-
Voltage-InputOffset:
75 µV
Current-Supply:
160µA
Current-Output/Channel:
12 mA
Voltage-SupplySpan(Min):
2.7 V
Voltage-SupplySpan(Max):
36 V
OperatingTemperature:
-40°C ~ 85°C
MountingType:
Surface Mount
