Renesas Electronics America Inc HA5351IBZ

Part No.:: HA5351IBZ

Manufacturer:: Renesas Electronics America Inc

Package:: 8-SOIC (0.154, 3.90mm Width)

Datasheet:: HA5351IBZ.pdf

Description:: IC SAMPL/HOLD 1 CIRCUIT 8SOIC

In Stock:: 477

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

HA5351IBZ Specifications

Package/Case:
8-SOIC (0.154, 3.90mm Width)
Packaging:
Tube
Series:
-
ProductStatus:
Active
AmplifierType:
Sample and Hold
NumberofCircuits:
1
OutputType:
-
SlewRate:
105V/µs
GainBandwidthProduct:
-
-3dbBandwidth:
40 MHz
Current-InputBias:
2.5 µA
Voltage-InputOffset:
2 mV
Current-Supply:
20mA
Current-Output/Channel:
25 mA
Voltage-SupplySpan(Min):
4.5 V
Voltage-SupplySpan(Max):
10 V
OperatingTemperature:
-40°C ~ 85°C
MountingType:
Surface Mount
