FTDI, Future Technology Devices International Ltd FT4232H MINI MODULE

Part No.:: FT4232H MINI MODULE

Manufacturer:: FTDI, Future Technology Devices International Ltd

Package:

Datasheet:: FT4232H MINI MODULE.pdf

Description:: MOD USB HS FT4232H EVAL

In Stock:: 448

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

FT4232H MINI MODULE Specifications

FT4232H MINI MODULE this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including FT4232H MINI MODULE price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for FT4232H MINI MODULE to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

FT4232H MINI MODULE information

Views：

FT4232H MINI MODULE Typical application Circuitry

FT4232H MINI MODULE

The FT4232H MINI MODULE is a compact USB to serial/MPSSE interface module based on the FTDI FT4232H chip. It provides four independent serial interfaces that can be configured for various communication protocols such as UART, SPI, I2C, and JTAG. Applications like instrumentation, debugging tools, and industrial control systems that need many serial interfaces frequently use this module.

Functionality: The FT4232H MINI MODULE acts as a bridge between USB and serial interfaces, offering high-speed data transfer rates and flexible configuration options. It supports different modes including asynchronous UART, synchronous bit-bang, and MPSSE for SPI and I2C protocols.

Applications: This module is suitable for applications like USB-to-serial conversion, microcontroller programming and debugging, interfacing with sensors or other peripherals, and developing custom communication protocols.

Parameters: The FT4232H MINI MODULE operates with a USB 2.0 Hi-Speed (480 Mbps) interface, supports baud rates up to 12 Mbps for UART, and provides configurable I/O voltage levels (1.8V, 2.5V, 3.3V, or 5V).

Specific Circuit Design for SPI Communication:

1. Power Supply: Connect the VCCIO pin (pin 1) of the FT4232H MINI MODULE to a 3.3V power source to set the I/O voltage level. Ensure that the GND pin (pin 19) is connected to the ground of your power supply.

2. USB Connection: Attach the USB mini-B connector of the module to a USB port on your computer to power the module and establish the USB interface.

3. SPI Configuration: For SPI communication, connect the SCK (Serial Clock) pin of channel B (pin 10) to the SCK pin of your target SPI device. Connect the MOSI (Master Out Slave In) pin of channel B (pin 11) to the MOSI pin of the target device, and the MISO (Master In Slave Out) pin of channel B (pin 13) to the MISO pin of the target device.

4. Chip Select: Use the GPIO pin of channel B (pin 14) as the Chip Select (CS) signal. Connect this pin to the CS pin of the target SPI device.

5. Ground Reference: Ensure that the ground of the FT4232H MINI MODULE is connected to the ground of the target device to provide a common reference.

Design Considerations:

- Power Supply: Verify that the power supply voltage matches the desired I/O voltage level for compatibility with connected devices.

- USB Bandwidth: Consider the USB bandwidth, especially when using multiple channels simultaneously, to avoid data transfer bottlenecks.

- Signal Integrity: Employ proper PCB layout techniques and impedance matching to maintain signal integrity, particularly at high data rates.

- Driver Installation: Ensure that the correct FTDI drivers are installed on your computer for the module to function properly.

- Device Configuration: Use the FTDI FT_Prog utility to configure the device settings, such as baud rate and protocol options, according to your application needs.

By adhering to these guidelines and following the specified circuit design, the FT4232H MINI MODULE can be effectively utilized in various applications requiring multiple serial interfaces.
