Fairchild Semiconductor FAN4174IS5X

Part No.:: FAN4174IS5X

Manufacturer:: Fairchild Semiconductor

Package:: SC-74A, SOT-753

Datasheet:: FAN4174IS5X.pdf

Description:: IC OPAMP VFB 1 CIRCUIT SOT23-5

In Stock:: 3726

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

FAN4174IS5X Specifications

Package/Case:
SC-74A, SOT-753
Packaging:
Bulk
Series:
-
ProductStatus:
Active
AmplifierType:
Voltage Feedback
NumberofCircuits:
1
OutputType:
Rail-to-Rail
SlewRate:
3V/µs
GainBandwidthProduct:
3.7 MHz
-3dbBandwidth:
3.7 MHz
Current-InputBias:
5 pA
Voltage-InputOffset:
8 mV
Current-Supply:
200µA
Current-Output/Channel:
33 mA
Voltage-SupplySpan(Min):
2.3 V
Voltage-SupplySpan(Max):
5.25 V
OperatingTemperature:
-40°C ~ 85°C
MountingType:
Surface Mount
