Decawave Limited DW1000-I-TR13

Part No.:: DW1000-I-TR13

Manufacturer:: Decawave Limited

Package:: 48-VFQFN Exposed Pad

Datasheet:: DW1000-I-TR13.pdf

Description:: IC RF TXRX 802.15.4 48QFN

In Stock:: 2984

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

DW1000-I-TR13 Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Discontinued at Mosen
Type:
TxRx Only
RFFamily/Standard:
802.15.4
Protocol:
IR-UWB
Modulation:
BPM, BPSK
Frequency:
3.5GHz ~ 6.5GHz
DataRate(Max):
6.8Mbps
Power-Output:
-10dBm
Sensitivity:
-
MemorySize:
-
SerialInterfaces:
SPI
GPIO:
-
Voltage-Supply:
2.8V ~ 3.6V
Current-Receiving:
64mA
Current-Transmitting:
31mA
OperatingTemperature:
-40°C ~ 85°C
MountingType:
Surface Mount
