Analog Devices Inc./Maxim Integrated DS32KHZSN#T&R

Part No.:: DS32KHZSN#T&R

Manufacturer:: Analog Devices Inc./Maxim Integrated

Package:: 16-SOIC (0.295, 7.50mm Width)

Datasheet:: DS32KHZSN#T&R.pdf

Description:: XTAL OSC TCXO 32.7680KHZ CMOS

In Stock:: 2553

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

DS32KHZSN#T&R Specifications

Package/Case:
16-SOIC (0.295, 7.50mm Width)
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
DS
ProductStatus:
Active
BaseResonator:
Crystal
Type:
TCXO
Frequency:
32.768 kHz
Function:
-
Output:
CMOS
Voltage-Supply:
5V
FrequencyStability:
±7.5ppm
AbsolutePullRange(APR):
-
OperatingTemperature:
-40°C ~ 85°C
SpreadSpectrumBandwidth:
-
Current-Supply(Max):
220µA
Ratings:
-
MountingType:
Surface Mount
Size/Dimension:
0.412 L x 0.300 W (10.46mm x 7.62mm)
