Texas Instruments DDC112U/1K

Part No.:: DDC112U/1K

Manufacturer:: Texas Instruments

Package:: 28-SOIC (0.295, 7.50mm Width)

Datasheet:: DDC112U/1K.pdf

Description:: IC ADC 20BIT SIGMA-DELTA 28SOIC

In Stock:: 6390

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

DDC112U/1K Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
Product Status:
Active
Number of Bits:
20
Sampling Rate(PerSecond):
3k
Number of Inputs:
2
Input Type:
Single Ended
Data Interface:
SPI
Configuration:
DSI-ADC
Ratio-S/H:ADC:
2:1
Number of A/D Converters:
1
Architecture:
Sigma-Delta
Reference Type:
External
Voltage-Supply Analog:
5V
Voltage-Supply Digital:
5V
Features:
Simultaneous Sampling
Operating Temperature:
0°C ~ 70°C
