Name: CC430F5133IRGZR
Brand: Texas Instruments
SKU: CC430F5133IRGZR
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Texas Instruments CC430F5133IRGZR

Part No.:: CC430F5133IRGZR

Manufacturer:: Texas Instruments

Package:: 48-VFQFN Exposed Pad

Datasheet:: CC430F5133IRGZR.pdf

Description:: IC RF TXRX+MCU ISM<1GHZ 48VFQFN

In Stock:: 3120

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

CC430F5133IRGZR Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Active
Type:
TxRx + MCU
RFFamily/Standard:
General ISM < 1GHz
Protocol:
-
Modulation:
2FSK, 2GFSK, ASK, MSK, OOK
Frequency:
300MHz ~ 348MHz, 389MHz ~ 464MHz, 779MHz ~ 928MHz
DataRate(Max):
500kBaud
Power-Output:
13dBm
Sensitivity:
-117dBm
MemorySize:
8kB Flash, 2kB SRAM
SerialInterfaces:
I²C, IrDA, JTAG, SPI, UART
GPIO:
30
Voltage-Supply:
2V ~ 3.6V
Current-Receiving:
15mA ~ 18.5mA
Current-Transmitting:
15mA ~ 36mA
OperatingTemperature:
-40°C ~ 85°C
MountingType:
Surface Mount

CC430F5133IRGZR this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including CC430F5133IRGZR price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for CC430F5133IRGZR to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

CC430F5133IRGZR information

Views：

CC430F5133IRGZR Typical application Circuitry

CC430F5133IRGZR

The CC430F5133IRGZR is a prominent member of Texas Instruments' CC430 series, a line of microcontrollers that uniquely combine an RF transceiver with an MSP430 microcontroller core. This series is specifically tailored for low-power wireless applications, making the CC430F5133IRGZR an excellent choice for projects requiring both RF communication and significant microcontroller processing capabilities, such as in sensor networks, home automation, and health monitoring systems. Its integration of RF functionality and a versatile microcontroller core in a single chip provides a compact and efficient solution for a wide range of wireless applications.

1. Power Supply (VCC Pin): The CC430F5133IRGZR's VCC pin has to be linked to a reliable power supply. The power supply voltage must be within the specified range to ensure the proper functioning of both the microcontroller and the RF transceiver.

2. Ground Connection (GND Pin): Every GND pin on the board must be linked to the system's ground.This common grounding is crucial for providing a stable reference for the entire circuit and ensuring optimal operation of the device.

3. RF Antenna Interface (RF_P, RF_N Pins): The RF_P and RF_N pins are differential antenna connections for the integrated RF transceiver. These should be connected to an antenna system, optimized for the operating frequency of the device.

4. Digital I/O Ports (Px.y Pins): The CC430F5133IRGZR features multiple digital I/O ports (Px.y, where x is the port number and y is the pin number). These ports provide flexible interface options for various digital functionalities based on the application's requirements.

5. Serial Communication Interfaces (USART0, USART1 Pins): The device includes pins for USART0 and USART1, supporting serial communication protocols such as SPI, I2C, and UART. These pins should be connected to corresponding interfaces on external devices for data transfer and control.

6. External Oscillator (XT2IN, XT2OUT Pins): The XT2IN and XT2OUT pins are used for connecting an external oscillator, which is necessary for providing clock signals for the microcontroller and RF transceiver, ensuring accurate timing and synchronization.

7. Programming and Debugging (TEST, RST/NMI, SBWTDIO, SBWTCK Pins): The TEST, RST/NMI (Reset/Non-Maskable Interrupt), SBWTDIO (Spy-Bi-Wire Data Input/Output), and SBWTCK (Spy-Bi-Wire Test Clock) pins are used for programming and debugging the microcontroller.

8. Power Decoupling and Filtering: Decoupling capacitors should be placed near the VCC pin to stabilize the power supply and minimize noise, essential for the reliable performance of both the microcontroller and RF transceiver.

9. PCB Layout Design: Designing the PCB for the CC430F5133IRGZR requires careful planning, especially for the RF traces. Ensuring short trace lengths for RF signals, proper impedance matching for the antenna, and a well-structured ground plane are critical for optimal device performance.

In summary, the CC430F5133IRGZR from the CC430 series is a powerful solution for wireless applications that require integration of RF communication and microcontroller functionalities. Implementing this device involves meticulous planning of power supply, grounding, RF antenna interface, digital I/O, serial communication, external oscillator, and programming/debugging connections. Additionally, incorporating decoupling capacitors and a carefully designed PCB are essential for maximizing the performance of the CC430F5133IRGZR in sophisticated wireless systems.
