Texas Instruments CC2652R74T0RGZR

Part No.:: CC2652R74T0RGZR

Manufacturer:: Texas Instruments

Package:: 48-VFQFN Exposed Pad

Datasheet:

Description:: SIMPLELINK ARM CORTEX-M4F MULTIP

In Stock:: 2695

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

CC2652R74T0RGZR Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
SimpleLink™
ProductStatus:
Active
Type:
TxRx + MCU
RFFamily/Standard:
802.15.4, Bluetooth
Protocol:
Bluetooth v5.2, Thread, Zigbee®
Modulation:
DSSS, O-QPSK
Frequency:
2.4GHz ~ 2.48GHz
DataRate(Max):
2Mbps
Power-Output:
5dBm
Sensitivity:
-104dBm
MemorySize:
704kB Flash, 144kB RAM
SerialInterfaces:
ADC, GPIO, I²C, I²S, JTAG, SPI, UART
GPIO:
31
Voltage-Supply:
1.8V ~ 3.8V
Current-Receiving:
7.1mA
Current-Transmitting:
7.6mA ~ 9.9mA
OperatingTemperature:
-40°C ~ 105°C (TA)
MountingType:
Surface Mount, Wettable Flank
