Texas Instruments CC2642R1TWFRTCRQ1

Part No.:: CC2642R1TWFRTCRQ1

Manufacturer:: Texas Instruments

Package:: 48-VFQFN Exposed Pad

Datasheet:: CC2642R1TWFRTCRQ1.pdf

Description:: AGAMA Q1 RTC PACKAGE

In Stock:: 3935

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

CC2642R1TWFRTCRQ1 Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
SimpleLink™
ProductStatus:
Active
Type:
TxRx + MCU
RFFamily/Standard:
Bluetooth
Protocol:
Bluetooth v5.1
Modulation:
-
Frequency:
2.4GHz
DataRate(Max):
2Mbps
Power-Output:
5dBm
Sensitivity:
-105dBm
MemorySize:
352kB Flash, 80kB RAM
SerialInterfaces:
GPIO, I²C, I²S, SPI, UART
GPIO:
31
Voltage-Supply:
1.8V ~ 3.63V
Current-Receiving:
6.9mA
Current-Transmitting:
7.3mA ~ 9.6mA
OperatingTemperature:
-40°C ~ 105°C (TA)
MountingType:
Surface Mount, Wettable Flank
