Texas Instruments CC1310F128RSMR

Part No.:: CC1310F128RSMR

Manufacturer:: Texas Instruments

Package:: 32-VFQFN Exposed Pad

Datasheet:: CC1310F128RSMR.pdf

Description:: IC RF TXRX+MCU ISM<1GHZ 32VFQFN

In Stock:: 3197

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

CC1310F128RSMR Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
SimpleLink™
ProductStatus:
Active
Type:
TxRx + MCU
RFFamily/Standard:
General ISM < 1GHz
Protocol:
-
Modulation:
DSSS, GFSK
Frequency:
300MHz ~ 930MHz
DataRate(Max):
50kbps
Power-Output:
14dBm
Sensitivity:
-124dBm
MemorySize:
128kB Flash, 20kB RAM
SerialInterfaces:
I²C, I²S, JTAG, SPI, UART
GPIO:
10
Voltage-Supply:
1.8V ~ 3.8V
Current-Receiving:
5.5mA
Current-Transmitting:
12.9mA ~ 22.6mA
OperatingTemperature:
-40°C ~ 85°C
MountingType:
Surface Mount

CC1310F128RSMR this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including CC1310F128RSMR price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for CC1310F128RSMR to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

CC1310F128RSMR information

Views：

CC1310F128RSMR Typical application Circuitry

CC1310F128RSMR

The CC1310F128RSMR is an integral part of the CC1310 series from Texas Instruments, renowned for its unique combination of an ARM Cortex-M3 microcontroller and a highly efficient RF transceiver. This series is specifically engineered for low-power, long-range wireless applications, which makes the CC1310F128RSMR a prime choice for IoT solutions, including smart metering, home automation, and industrial monitoring systems. The dual functionality of the CC1310F128RSMR, encompassing both advanced computational capabilities and robust wireless communication, is particularly advantageous for systems where compactness and energy efficiency are paramount.

1. Power Supply Lines (VDDS, DVDD Pins): The VDDS and DVDD pins of the CC1310F128RSMR should be connected to a consistent power source. These pins provide power to the digital and analog sections of the chip, respectively, and are essential for maintaining the device's operational integrity within its specified low-voltage range.

2. Grounding Connections (GND Pins): Every single GND pin needs to be linked to the system's ground. This ensures a stable ground reference for the entire circuit, which is vital for the proper functioning of the integrated microcontroller and RF transceiver.

3. RF Interface (RF_P, RF_N Pins): The RF_P and RF_N pins are the differential antenna connections for the RF part of the device. These should be connected to an antenna setup, which may include an RF matching network tailored to the specific frequency requirements and the application's needs.

4. Digital Input/Output (DIOx Pins): The CC1310F128RSMR is equipped with various DIOx pins that offer flexible digital input/output functionalities. These pins can be programmed for multiple purposes such as GPIO, serial communications, or control signals, depending on the specific needs of your application.

5. Serial Communication Ports (UART, SPI, I2C Pins): The device includes dedicated pins for standard serial communication protocols like UART, SPI, and I2C. These pins should be interfaced with compatible devices or microcontrollers for efficient data exchange and control.

6. External Oscillator (XOSC_H, XOSC_L Pins): Connecting an external crystal oscillator to the XOSC_H and XOSC_L pins is crucial for providing accurate clock signals to both the microcontroller and the RF transceiver components.

7. Microcontroller Reset (RESET_N Pin): The RESET_N pin is designed for external reset control of the microcontroller. This pin can be utilized for a manual reset mechanism or can be left disconnected if such functionality is not required.

8. Power Stabilization (Decoupling Capacitors): Employ decoupling capacitors near the VDDS and DVDD pins to stabilize the power supply and minimize potential noise. This is especially important in RF applications to ensure signal clarity.

9. PCB Layout Strategy: Designing the PCB for the CC1310F128RSMR should focus on minimizing interference between digital and analog sections. Attention should be given to the layout of RF pathways, ensuring short trace lengths and proper impedance matching for the antenna connection. A thorough ground plane strategy and meticulous trace routing are also essential for the device's optimal performance.

In summary, the CC1310F128RSMR, as a member of the CC1310 series, is adept at handling complex tasks in wireless communication systems, especially in IoT applications. Its deployment involves careful planning of power connections, grounding, RF interfacing, digital I/O setup, and serial communications. Additionally, integrating an external oscillator, implementing reset functionality, and ensuring power stability with decoupling capacitors, all within a well-designed PCB, are critical to fully leveraging the capabilities of the CC1310F128RSMR in sophisticated wireless solutions.
