Name: BAS321JF
Brand: Nexperia USA Inc.
SKU: BAS321JF
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Nexperia USA Inc. BAS321JF

Part No.:: BAS321JF

Manufacturer:: Nexperia USA Inc.

Package:: SC-76, SOD-323

Datasheet:: BAS321JF.pdf

Description:: BAS321J/SOD323/SOD2

In Stock:: 3934

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

BAS321JF Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
Automotive, AEC-Q101
RoHS:
RoHS
Speed:
Fast Recovery =< 500ns, > 200mA (Io)
Diode Type:
Standard
Part Status:
Active
Mounting Type:
Surface Mount
Capacitance @ Vr, F:
2pF @ 0V, 1MHz
Reverse Recovery Time (trr):
50 ns
Current - Reverse Leakage @ Vr:
100 nA @ 200 V
Voltage - DC Reverse (Vr) (Max):
250 V
Current - Average Rectified (Io):
250mA (DC)
Operating Temperature - Junction:
150°C (Max)
Voltage - Forward (Vf) (Max) @ If:
1.25 V @ 200 mA
