Nexperia USA Inc. BAS321/8F

Part No.:: BAS321/8F

Manufacturer:: Nexperia USA Inc.

Package:: SC-76, SOD-323

Datasheet:: BAS321/8F.pdf

Description:: DIODE GEN PURP 200V 250MA SOD323

In Stock:: 2012

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

BAS321/8F Specifications

Packaging:
Tape & Reel (TR)
Series:
RoHS:
RoHS
Speed:
Fast Recovery =< 500ns, > 200mA (Io)
Diode Type:
Standard
Part Status:
Active
Mounting Type:
Surface Mount
Capacitance @ Vr, F:
2pF @ 0V, 1MHz
Reverse Recovery Time (trr):
50 ns
Current - Reverse Leakage @ Vr:
100 nA @ 200 V
Voltage - DC Reverse (Vr) (Max):
200 V
Current - Average Rectified (Io):
250mA (DC)
Operating Temperature - Junction:
150°C (Max)
Voltage - Forward (Vf) (Max) @ If:
1.25 V @ 200 mA
