ON Semiconductor BAS16XV2T1G

Part No.:: BAS16XV2T1G

Manufacturer:: ON Semiconductor

Package:: SC-79, SOD-523

Datasheet:: BAS16XV2T1G.pdf

Description:: DIODE GEN PURP 100V 200MA SOD523

In Stock:: 2101

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

BAS16XV2T1G Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®,Bulk
Series:
RoHS:
RoHS
Speed:
Small Signal =< 200mA (Io), Any Speed
Diode Type:
Standard
Part Status:
Active
Mounting Type:
Surface Mount
Capacitance @ Vr, F:
2pF @ 0V, 1MHz
Reverse Recovery Time (trr):
6 ns
Current - Reverse Leakage @ Vr:
1 µA @ 100 V
Voltage - DC Reverse (Vr) (Max):
100 V
Current - Average Rectified (Io):
200mA (DC)
Operating Temperature - Junction:
-55°C ~ 150°C
Voltage - Forward (Vf) (Max) @ If:
1.25 V @ 150 mA
