NextGen Components B5819WS

Part No.:: B5819WS

Manufacturer:: NextGen Components

Package:: -

Datasheet:: B5819WS.pdf

Description:: SCHOTTKY DIODE SOD-323 40V 1A

In Stock:: 3723000

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

B5819WS Specifications

Packaging:
Tape & Reel (TR)
Series:
SOD-323
RoHS:
RoHS
Speed:
Fast Recovery =< 500ns, > 200mA (Io)
Diode Type:
Schottky
Part Status:
Active
Mounting Type:
Surface Mount
Capacitance @ Vr, F:
110pF @ 4V, 1MHz
Reverse Recovery Time (trr):
-
Current - Reverse Leakage @ Vr:
1 mA @ 40 V
Voltage - DC Reverse (Vr) (Max):
40 V
Current - Average Rectified (Io):
1A
Operating Temperature - Junction:
-
Voltage - Forward (Vf) (Max) @ If:
600 mV @ 1 A

B5819WS this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including B5819WS price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for B5819WS to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

B5819WS information

Views：

B5819WS Typical application Circuitry

B5819WS

A Schottky barrier diode with minimal forward voltage drop and quick switching is the B5819WS. With a maximum reverse voltage of 40 V and a forward current capacity of 1 A, it can be used for voltage clamping, power rectification, and high-frequency applications.

Application Scenario: Reverse Polarity Protection Circuit

In a reverse polarity protection circuit, the B5819WS can be used to protect sensitive electronic components from damage caused by incorrect battery orientation.

Circuit Connection:

1. Diode Orientation: Connect the anode of the B5819WS to the positive terminal of the power source (e.g., a battery). This ensures that the diode blocks current flow when the battery is connected in reverse.

2. Load Connection: Connect the cathode of the B5819WS to the positive input of the device or circuit being protected. The diode allows current to flow when the battery is correctly oriented.

3. Grounding: Connect the negative terminal of the power source and the negative input of the protected device to a common ground.

4. Bypass Option: For further overcurrent protection, you can optionally connect a fuse or a PTC (Positive Temperature Coefficient) thermistor in series with the B5819WS.

Design Considerations:

- Forward Voltage Drop: Consider the forward voltage drop of the B5819WS and its impact on the overall system voltage. The low forward voltage drop of Schottky diodes minimizes power loss.

- Current Rating: Ensure that the forward current rating of the B5819WS exceeds the maximum expected load current to prevent diode failure.

- Thermal Management: Monitor the power dissipation in the B5819WS and provide adequate heat sinking if necessary, especially in high-current applications.

- Protection Coordination: If additional protection components are used, ensure that they are coordinated to provide effective protection without compromising system performance.

By incorporating these design considerations, the B5819WS can be effectively utilized in a reverse polarity protection circuit to safeguard sensitive electronic components from damage due to incorrect battery orientation, ensuring reliable operation and longevity of the system.
