Diodes Incorporated B360A-13-F

Part No.:: B360A-13-F

Manufacturer:: Diodes Incorporated

Package:: DO-214AC, SMA

Datasheet:: B360A-13-F.pdf

Description:: DIODE SCHOTTKY 60V 3A SMA

In Stock:: 2516

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

B360A-13-F Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
Automotive, AEC-Q101
RoHS:
RoHS
Speed:
Fast Recovery =< 500ns, > 200mA (Io)
Diode Type:
Schottky
Part Status:
Active
Mounting Type:
Surface Mount
Capacitance @ Vr, F:
200pF @ 4V, 1MHz
Reverse Recovery Time (trr):
-
Current - Reverse Leakage @ Vr:
500 µA @ 60 V
Voltage - DC Reverse (Vr) (Max):
60 V
Current - Average Rectified (Io):
3A
Operating Temperature - Junction:
-55°C ~ 150°C
Voltage - Forward (Vf) (Max) @ If:
700 mV @ 3 A
