Texas Instruments ADS8865IDGSR

Part No.:: ADS8865IDGSR

Manufacturer:: Texas Instruments

Package:: 10-TFSOP, 10-MSOP (0.118, 3.00mm Width)

Datasheet:: ADS8865IDGSR.pdf

Description:: IC ADC 16BIT SAR 10VSSOP

In Stock:: 4358

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ADS8865IDGSR Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
microPOWER™
Product Status:
Active
Number of Bits:
16
Sampling Rate(PerSecond):
400k
Number of Inputs:
1
Input Type:
Differential
Data Interface:
SPI
Configuration:
S/H-ADC
Ratio-S/H:ADC:
1:1
Number of A/D Converters:
1
Architecture:
SAR
Reference Type:
External
Voltage-Supply Analog:
2.7V ~ 3.6V
Voltage-Supply Digital:
1.65V ~ 3.6V
Features:
-
Operating Temperature:
-40°C ~ 85°C
