Texas Instruments ADS8688IDBTR

Part No.:: ADS8688IDBTR

Manufacturer:: Texas Instruments

Package:: 38-TFSOP (0.173, 4.40mm Width)

Datasheet:: ADS8688IDBTR.pdf

Description:: IC ADC 16BIT SAR 38TSSOP

In Stock:: 2182

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ADS8688IDBTR Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
Product Status:
Active
Number of Bits:
16
Sampling Rate(PerSecond):
500k
Number of Inputs:
8
Input Type:
Differential, Single Ended
Data Interface:
SPI
Configuration:
PGA-MUX-S/H-ADC
Ratio-S/H:ADC:
1:1
Number of A/D Converters:
1
Architecture:
SAR
Reference Type:
External, Internal
Voltage-Supply Analog:
5V
Voltage-Supply Digital:
1.65V ~ 5.25V
Features:
PGA
Operating Temperature:
-40°C ~ 125°C
