Texas Instruments ADS8568SRGCR

Part No.:: ADS8568SRGCR

Manufacturer:: Texas Instruments

Package:: 64-VFQFN Exposed Pad

Datasheet:: ADS8568SRGCR.pdf

Description:: IC ADC 16BIT SAR 64VQFN

In Stock:: 2156

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ADS8568SRGCR Specifications

Packaging:
Tape & Reel (TR)
Series:
-
Product Status:
Active
Number of Bits:
16
Sampling Rate(PerSecond):
500k
Number of Inputs:
8
Input Type:
Single Ended
Data Interface:
SPI, Parallel
Configuration:
S/H-ADC
Ratio-S/H:ADC:
1:1
Number of A/D Converters:
1
Architecture:
SAR
Reference Type:
External, Internal
Voltage-Supply Analog:
5V
Voltage-Supply Digital:
2.7V ~ 5.5V
Features:
Simultaneous Sampling
Operating Temperature:
-40°C ~ 125°C

ADS8568SRGCR this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including ADS8568SRGCR price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for ADS8568SRGCR to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

ADS8568SRGCR information

Views：

ADS8568SRGCR Typical application Circuitry

The ADS8568SRGCR is a high-performance, 16-bit analog-to-digital converter (ADC) with 8 channels. It comes with an impressive sampling rate of up to 500 kSPS and includes a parallel interface for easier data transfer. This ADC is specifically aimed at applications requiring multi-channel data acquisition in high-precision scenarios.

Domains of ADS8568SRGCR Applications

- Test and Measurement Instruments

- Medical Imaging Systems

- Energy Monitoring

- Process Control

Features of ADS8568SRGCR

- 16-bit ADC resolution

- Sampling rates up to 500 kSPS

- 8-channel multi-sequencer

- High Signal-to-Noise Ratio (SNR)

- Parallel interface

Detailed Circuit Connection for ADS8568SRGCR in a Medical Imaging System

Components Required:

1. ADS8568SRGCR ADC

2. Microcontroller with parallel interface

3. Voltage Reference IC

4. Operational Amplifiers for Signal Conditioning

5. Required Passive Components (Capacitors, Resistors)

Step-by-Step Pin Assignments and Circuit Connections

1.Powering the Device: Connect VDD (Pin 1) to a stable 5V power supply. Put a 10 F capacitor next to the VDD and GND pins to increase stability.

2.Effective Grounding: For pin AGND (Pin 18), establish a low-noise analog ground.

3.Voltage Reference Connection: Connect a 2.5V voltage reference to VREF (Pin 9) for consistent ADC readings.

4.Signal Conditioning: Before connecting to any of the AINx pins (e.g., AIN0 at Pin 13), pass the analog input through an operational amplifier for conditioning.

5.Parallel Interface: Connect the DB0 to DB15 pins (Pins 32-47) to the parallel interface on the microcontroller.

6.Clock and Control Pins: Connect the CLK (Pin 27) to the microcontroller's clock output. Ensure the CNVST (Pin 28) pin is also interfaced with the microcontroller for conversion initiation.

7.End of Conversion Indication: Connect EOC (Pin 30) to an interrupt or a GPIO pin on the microcontroller to indicate the end of conversion.

Design Considerations

1.Noise Reduction: When designing the circuit, it's critical to minimize noise, especially on the analog inputs and VREF pin. Low-pass filters might be useful in this situation.

2.Signal Integrity: Maintain impedance matching and ensure that the trace lengths are uniform for all parallel interface lines to prevent timing skew.

3.Power Decoupling: Additional decoupling capacitors may be required to reduce the high-frequency noise in the power supply lines.

4.Data Timing: The parallel interface and clock must be accurately timed to ensure reliable data retrieval from the ADS8568SRGCR.

5.Temperature Fluctuations: Take into account any potential temperature drift in component values and how that might affect the ADC accuracy.

Applications requiring both high speed and precision are best served by the ADS8568SRGCR. Special attention must be paid to noise management and signal integrity to fully utilize the capabilities of this ADC.
