Texas Instruments ADS7951SBDBT

Part No.:: ADS7951SBDBT

Manufacturer:: Texas Instruments

Package:: 30-TFSOP (0.173, 4.40mm Width)

Datasheet:: ADS7951SBDBT.pdf

Description:: IC ADC 12BIT SAR 30TSSOP

In Stock:: 3859

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ADS7951SBDBT Specifications

Packaging:
Tube
Series:
microPOWER™
Product Status:
Active
Number of Bits:
12
Sampling Rate(PerSecond):
1M
Number of Inputs:
8
Input Type:
Single Ended
Data Interface:
SPI
Configuration:
MUX-S/H-ADC
Ratio-S/H:ADC:
1:1
Number of A/D Converters:
1
Architecture:
SAR
Reference Type:
External
Voltage-Supply Analog:
2.7V ~ 5.25V
Voltage-Supply Digital:
1.7V ~ 5.25V
Features:
-
Operating Temperature:
-40°C ~ 125°C
