Name: ADS7866IDBVR
Brand: Texas Instruments
SKU: ADS7866IDBVR
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Texas Instruments ADS7866IDBVR

Part No.:: ADS7866IDBVR

Manufacturer:: Texas Instruments

Package:: SOT-23-6

Datasheet:: ADS7866IDBVR.pdf

Description:: IC ADC 12BIT SAR SOT23-6

In Stock:: 2759

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ADS7866IDBVR Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®,Bulk
Series:
microPOWER™
Product Status:
Active
Number of Bits:
12
Sampling Rate(PerSecond):
200k
Number of Inputs:
1
Input Type:
Single Ended
Data Interface:
SPI
Configuration:
S/H-ADC
Ratio-S/H:ADC:
1:1
Number of A/D Converters:
1
Architecture:
SAR
Reference Type:
External
Voltage-Supply Analog:
1.2V ~ 3.6V
Voltage-Supply Digital:
1.2V ~ 3.6V
Features:
-
Operating Temperature:
-40°C ~ 85°C
