Texas Instruments ADS62P45IRGCR

Part No.:: ADS62P45IRGCR

Manufacturer:: Texas Instruments

Package:: 64-VFQFN Exposed Pad

Datasheet:: ADS62P45IRGCR.pdf

Description:: IC ADC 14BIT PIPELINED 64VQFN

In Stock:: 6365

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ADS62P45IRGCR Specifications

Packaging:
Tape & Reel (TR),Bulk
Series:
-
Product Status:
Active
Number of Bits:
14
Sampling Rate(PerSecond):
125M
Number of Inputs:
2
Input Type:
Differential
Data Interface:
LVDS - Parallel, Parallel
Configuration:
S/H-ADC
Ratio-S/H:ADC:
1:1
Number of A/D Converters:
2
Architecture:
Pipelined
Reference Type:
External, Internal
Voltage-Supply Analog:
3V ~ 3.6V
Voltage-Supply Digital:
1.65V ~ 3.6V
Features:
Simultaneous Sampling
Operating Temperature:
-40°C ~ 85°C
