Texas Instruments ADS6128IRGZR

Part No.:: ADS6128IRGZR

Manufacturer:: Texas Instruments

Package:: 48-VFQFN Exposed Pad

Datasheet:: ADS6128IRGZR.pdf

Description:: IC ADC 12BIT PIPELINED 48VQFN

In Stock:: 3754

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ADS6128IRGZR Specifications

Packaging:
Tape & Reel (TR)
Series:
-
Product Status:
Active
Number of Bits:
12
Sampling Rate(PerSecond):
210M
Number of Inputs:
1
Input Type:
Differential
Data Interface:
LVDS - Parallel, Parallel
Configuration:
S/H-ADC
Ratio-S/H:ADC:
1:1
Number of A/D Converters:
1
Architecture:
Pipelined
Reference Type:
External, Internal
Voltage-Supply Analog:
3V ~ 3.6V
Voltage-Supply Digital:
1.7V ~ 1.9V
Features:
-
Operating Temperature:
-40°C ~ 85°C
