Texas Instruments ADS1258IRTCTG4

Part No.:: ADS1258IRTCTG4

Manufacturer:: Texas Instruments

Package:: 48-VFQFN Exposed Pad

Datasheet:: ADS1258IRTCTG4.pdf

Description:: IC ADC 24BIT SIGMA-DELTA 48VQFN

In Stock:: 3024

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ADS1258IRTCTG4 Specifications

Packaging:
Tape & Reel (TR)
Series:
-
Product Status:
Discontinued at Mosen
Number of Bits:
24
Sampling Rate(PerSecond):
125k
Number of Inputs:
8, 16
Input Type:
Differential, Single Ended
Data Interface:
SPI
Configuration:
MUX-ADC
Ratio-S/H:ADC:
-
Number of A/D Converters:
1
Architecture:
Sigma-Delta
Reference Type:
External
Voltage-Supply Analog:
5V
Voltage-Supply Digital:
2.7V ~ 5.25V
Features:
-
Operating Temperature:
-40°C ~ 105°C
