Texas Instruments ADS124S08IRHBR

Part No.:: ADS124S08IRHBR

Manufacturer:: Texas Instruments

Package:: 32-VFQFN Exposed Pad

Datasheet:: ADS124S08IRHBR.pdf

Description:: IC ADC 24BIT SIGMA-DELTA 32VQFN

In Stock:: 3905

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ADS124S08IRHBR Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
Product Status:
Active
Number of Bits:
24
Sampling Rate(PerSecond):
4k
Number of Inputs:
12
Input Type:
Single Ended
Data Interface:
SPI
Configuration:
MUX-PGA-ADC
Ratio-S/H:ADC:
0:1
Number of A/D Converters:
1
Architecture:
Sigma-Delta
Reference Type:
External, Internal
Voltage-Supply Analog:
2.7V ~ 5.25V
Voltage-Supply Digital:
2.7V ~ 3.6V
Features:
PGA
Operating Temperature:
-50°C ~ 125°C

ADS124S08IRHBR this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including ADS124S08IRHBR price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for ADS124S08IRHBR to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

ADS124S08IRHBR information

Views：

ADS124S08IRHBR Typical application Circuitry

The ADS124S08IRHBR is a precision, 24-bit, analog-to-digital converter (ADC) from Texas Instruments, designed for a variety of applications including temperature sensor measurements, thermocouples, resistance temperature detectors (RTDs), and others. Here's a general outline on how to connect the ADS124S08IRHBR:

1. Power Supply: The ADS124S08IRHBR operates from a power supply voltage between 2.7V and 5.3V. Connect the AVDD pin to your analog power supply and the DVDD pin to your digital power supply.
2. Ground Connections: The device has two ground pins - Analog Ground (AGND) and Digital Ground (DGND). Both pins should be connected to the ground of your system.
3. Analog Inputs: The ADS124S08IRHBR has 8 differential or 16 single-ended inputs via its multiplexer. You can connect your sensor or other analog signals to these input pins as per your requirement.
4. Reference Voltage: The device uses an external reference voltage which can be connected at the REFNP and REFNN pins.
5. Clock Input: You can provide an external clock signal to the device via the CLKIN pin. Alternatively, you can use the ADC's internal oscillator.
6. Digital Interface: The digital interface of ADS124S08IRHBR is SPI-compatible. Connect your microcontroller or digital system to the CS (chip select), SCLK (serial clock), DIN (data input), DOUT (data output), and DRDY (data ready) pins.
7. Reset Pin: The RESET pin can be used to perform a hardware reset on the device if needed.
8. Decoupling Capacitors: Connect decoupling capacitors close to the AVDD, DVDD, REFNP, and REFNN pins to filter out any voltage noise and to stabilize the power supply.
9. Gain Selection: The ADS124S08IRHBR has a built-in programmable gain amplifier (PGA) which can be configured through the SPI interface.
The specific values of the external components such as the decoupling capacitors and the resistor connected to the RESET pin, and more in-depth details, can be found in the ADS124S08IRHBR datasheet. This document will provide specific device characteristics, limitations, and more detailed information about the application circuit.
