Texas Instruments ADS114S08IRHBR

Part No.:: ADS114S08IRHBR

Manufacturer:: Texas Instruments

Package:: 32-VFQFN Exposed Pad

Datasheet:: ADS114S08IRHBR.pdf

Description:: IC ADC 16BIT SIGMA-DELTA 32VQFN

In Stock:: 3874

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ADS114S08IRHBR Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
Product Status:
Active
Number of Bits:
16
Sampling Rate(PerSecond):
4k
Number of Inputs:
12
Input Type:
Differential, Pseudo-Differential, Single Ended
Data Interface:
SPI
Configuration:
MUX-PGA-ADC
Ratio-S/H:ADC:
-
Number of A/D Converters:
1
Architecture:
Sigma-Delta
Reference Type:
External, Internal
Voltage-Supply Analog:
±2.5V, 2.7V ~ 5.25V
Voltage-Supply Digital:
2.7V ~ 3.6V
Features:
PGA
Operating Temperature:
-50°C ~ 125°C
