Texas Instruments ADC128S102CIMTX

Part No.:: ADC128S102CIMTX

Manufacturer:: Texas Instruments

Package:: 16-TSSOP (0.173, 4.40mm Width)

Datasheet:: ADC128S102CIMTX.pdf

Description:: IC ADC 12BIT SAR 16TSSOP

In Stock:: 3459

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ADC128S102CIMTX Specifications

Packaging:
Tape & Reel (TR)
Series:
-
Product Status:
Obsolete
Number of Bits:
12
Sampling Rate(PerSecond):
1M
Number of Inputs:
8
Input Type:
Single Ended
Data Interface:
SPI, DSP
Configuration:
MUX-S/H-ADC
Ratio-S/H:ADC:
1:1
Number of A/D Converters:
1
Architecture:
SAR
Reference Type:
Supply
Voltage-Supply Analog:
2.7V ~ 5.25V
Voltage-Supply Digital:
2.7V ~ 5.25V
Features:
-
Operating Temperature:
-40°C ~ 105°C
