Texas Instruments ADC12038CIWMX/NOPB

Part No.:: ADC12038CIWMX/NOPB

Manufacturer:: Texas Instruments

Package:: 28-SOIC (0.295, 7.50mm Width)

Datasheet:: ADC12038CIWMX/NOPB.pdf

Description:: IC ADC 12BIT SAR 28SOIC

In Stock:: 2437

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ADC12038CIWMX/NOPB Specifications

Packaging:
Tape & Reel (TR),Bulk
Series:
-
Product Status:
Obsolete
Number of Bits:
12
Sampling Rate(PerSecond):
114k
Number of Inputs:
4, 8
Input Type:
Differential, Pseudo-Differential, Single Ended
Data Interface:
SPI
Configuration:
MUX-S/H-ADC
Ratio-S/H:ADC:
1:1
Number of A/D Converters:
1
Architecture:
SAR
Reference Type:
External
Voltage-Supply Analog:
5V
Voltage-Supply Digital:
5V
Features:
-
Operating Temperature:
-40°C ~ 85°C

ADC12038CIWMX/NOPB this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including ADC12038CIWMX/NOPB price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for ADC12038CIWMX/NOPB to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

ADC12038CIWMX/NOPB information

Views：

ADC12038CIWMX/NOPB Typical application Circuitry

ADC12038CIWMX NOPB

A high-precision, 12-bit analog-to-digital converter (ADC) designed for applications that need accurate and quick conversions of analog signals to digital data is the ADC12038CIWMX/NOPB. This ADC is particularly suitable for environments where low power consumption and high-speed data acquisition are critical.

Application Scenario:

Portable medical devices are a critical application for the ADC12038CIWMX/NOPB. These devices often require precise measurements of physiological signals (e.g., ECG, blood pressure, and glucose levels) for monitoring and diagnostic purposes. These analog signals are made digitally easier by the ADC12038CIWMX/NOPB, allowing for more sophisticated signal processing and analysis.

Parameter Features:

- 12-Bit Resolution: Ensures detailed and accurate digital representation of the analog signal.

- Low Power Consumption: Perfect for portable devices that run on batteries where power economy is crucial.

- High-Speed Operation: Capable of fast conversion rates, essential for real-time monitoring and data processing.

- Wide Input Range: Accommodates various sensor outputs, making it adaptable for different medical measurement applications.

Detailed Circuit Connection Example:

For a portable ECG monitor, the integration of the ADC12038CIWMX/NOPB involves several critical steps:

1. Power Integration: Connect the VDD pin of the ADC12038CIWMX/NOPB to a stable +5V power source. Make use of a bypass capacitor close to the VDD pin to provide a steady and pure supply.

2. Sensor Input Connection: Attach the ECG sensor's analog output to the VIN+ pin of the ADC12038CIWMX/NOPB. If the application requires, connect the VIN- to a reference voltage or use it for a differential signal setup to enhance signal quality.

3. Grounding Strategy: Ensure the AGND pin is connected to the device's analog ground plane. Separating analog and digital ground planes is crucial to minimize noise interference.

4. Digital Interface Setup: Link the digital output pins (D0-D11) of the ADC12038CIWMX/NOPB to the input pins of the processing unit or microcontroller. This connection allows the digitized data to be further analyzed and processed.

5. Clock Provision: Apply a precise and stable clock signal to the CLK pin, as the conversion speed of the ADC12038CIWMX/NOPB directly depends on this clock.

Design Considerations:

When incorporating the ADC12038CIWMX/NOPB into a circuit, several design aspects need attention:

- Signal Integrity: Prioritize short, direct paths for analog signals and shield them from digital noise sources to preserve integrity.

- Stable Power Supply: Implement decoupling techniques and consider using a low-noise, regulated power supply to minimize disturbances that could affect ADC accuracy.

- Clock Quality: A clean and stable clock source is paramount for precise conversions. Ensure the clock signal is free from jitter and noise.

- Environmental Robustness: Given the portable nature of medical devices, design for robustness against temperature fluctuations, movement, and electromagnetic interference (EMI).

Incorporating the ADC12038CIWMX/NOPB in portable medical devices or similar applications demands meticulous planning and design to ensure accurate, reliable analog-to-digital conversion under various conditions.
