Name: ADC09QJ800AAVTQ1
Brand: Texas Instruments
SKU: ADC09QJ800AAVTQ1
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Texas Instruments ADC09QJ800AAVTQ1

Part No.:: ADC09QJ800AAVTQ1

Manufacturer:: Texas Instruments

Package:: 144-FBGA, FCBGA

Datasheet:

Description:: IC ANALOG TO DIGITAL CONVERTER

In Stock:: 3966

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ADC09QJ800AAVTQ1 Specifications

Packaging:
Tape & Reel (TR)
Series:
Automotive, AEC-Q100
Product Status:
Active
Number of Bits:
9
Sampling Rate(PerSecond):
800M
Number of Inputs:
4
Input Type:
Differential
Data Interface:
JESD204C, Serial
Configuration:
ADC
Ratio-S/H:ADC:
0:4
Number of A/D Converters:
4
Architecture:
Pipelined, SAR
Reference Type:
-
Voltage-Supply Analog:
1.05V ~ 1.15V, 1.8V ~ 2V
Voltage-Supply Digital:
1.05V ~ 1.15V
Features:
-
Operating Temperature:
-40°C ~ 125°C
