Texas Instruments ADC0832CCN

Part No.:: ADC0832CCN

Manufacturer:: Texas Instruments

Package:: 8-DIP (0.300, 7.62mm)

Datasheet:: ADC0832CCN.pdf

Description:: IC ADC 8BIT SAR 8DIP

In Stock:: 2650

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ADC0832CCN Specifications

Packaging:
Tube
Series:
-
Product Status:
Obsolete
Number of Bits:
8
Sampling Rate(PerSecond):
31.25k
Number of Inputs:
2
Input Type:
Differential, Pseudo-Differential, Single Ended
Data Interface:
SPI
Configuration:
MUX-ADC
Ratio-S/H:ADC:
-
Number of A/D Converters:
1
Architecture:
SAR
Reference Type:
External
Voltage-Supply Analog:
4.5V ~ 6.3V
Voltage-Supply Digital:
4.5V ~ 6.3V
Features:
-
Operating Temperature:
-40°C ~ 85°C

ADC0832CCN this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including ADC0832CCN price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for ADC0832CCN to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

ADC0832CCN information

Views：

ADC0832CCN Typical application Circuitry

ADC0832CCN

The ADC0832CCN is part of the ADC0832 series, which is a line of 8-bit successive approximation analog-to-digital converters developed by Texas Instruments. This series is known for its compact size, ease of use, and efficiency in converting analog signals to digital form, making it suitable for applications such as data acquisition, battery-operated devices, and various forms of sensor reading and monitoring. The "CCN" suffix denotes that this device is available in a DIP (Dual In-line Package), which is favored for its ease of handling and suitability for prototyping and small-scale production.

1. 8-Bit Successive Approximation ADC: The ADC0832CCN specializes in performing analog-to-digital conversions with 8-bit resolution, offering a balance between conversion speed and resolution that is adequate for many applications requiring moderate precision.

2. Single Power Supply Operation (VCC, GND): This device operates with a single power supply connected to the VCC pin, typically requiring 5V, aligning with common digital logic levels for straightforward system integration. The ground connection is established through the GND pin, which is critical for the ADC's stability and the integrity of its conversion process.

3. Analog Input Channels (CH0, CH1): The ADC0832CCN features two single-ended analog input channels, CH0 and CH1, allowing the device to sample two different analog signals. This dual-channel capability provides flexibility in monitoring multiple analog sources.

4. Digital Communication Pins (CS, DI, DO, CLK): The Chip Select (CS) pin is used to activate the ADC, enabling data conversion when driven low. The Data Input (DI) pin receives configuration commands and control signals from the microcontroller. The Data Output (DO) pin provides the digital conversion result to the microcontroller. The Serial Clock (CLK) pin inputs the clock signal necessary for synchronizing the data communication, ensuring accurate timing for data transfer.

5. Decoupling for Noise Reduction: To ensure optimal performance and minimize noise in the ADC conversion process, it is advisable to use decoupling capacitors near the VCC and GND pins. These capacitors help to stabilize the power supply and filter out noise, thereby improving the accuracy of the ADC conversions.

6. Signal Routing for Analog Inputs: When incorporating the ADC0832CCN into a circuit, careful consideration should be given to the routing of the analog input signals to CH0 and CH1. Keeping these traces short and shielded, if possible, can help to minimize noise and interference, preserving the quality of the analog signal.

7. Thermal Considerations: Although the ADC0832CCN is designed for low power consumption, it is still advisable to consider thermal management in the overall design, especially when used in environments with elevated ambient temperatures or in applications with continuous operation, to ensure reliable performance.

8. Application Versatility: Due to its simplicity, moderate resolution, and dual-channel input, the ADC0832CCN is suitable for a wide range of applications, including sensor interfacing, basic data acquisition systems, and portable devices where power efficiency and compact size are valued.

Integrating the ADC0832CCN into a system design involves strategic planning regarding power supply management, analog signal routing, and digital communication interfacing to fully leverage its capabilities as an 8-bit ADC. By adhering to these design principles, the ADC0832CCN can significantly enhance the performance and reliability of systems requiring efficient and straightforward analog-to-digital conversion.
