Analog Devices Inc. ADA4896-2ARMZ-R7

Part No.:: ADA4896-2ARMZ-R7

Manufacturer:: Analog Devices Inc.

Package:: 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)

Datasheet:

Description:: IC VOLTAGE FEEDBACK 2 CIRC 8MSOP

In Stock:: 43742

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ADA4896-2ARMZ-R7 Specifications

Package/Case:
8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Active
AmplifierType:
Voltage Feedback
NumberofCircuits:
2
OutputType:
Rail-to-Rail
SlewRate:
120V/µs
GainBandwidthProduct:
90 MHz
-3dbBandwidth:
230 MHz
Current-InputBias:
4 µA
Voltage-InputOffset:
28 µV
Current-Supply:
3mA (x2 Channels)
Current-Output/Channel:
80 mA
Voltage-SupplySpan(Min):
3 V
Voltage-SupplySpan(Max):
10 V
OperatingTemperature:
-40°C ~ 125°C
MountingType:
Surface Mount
