Analog Devices Inc. AD8606ARMZ-R2

Part No.:: AD8606ARMZ-R2

Manufacturer:: Analog Devices Inc.

Package:: 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)

Datasheet:: AD8606ARMZ-R2.pdf

Description:: IC OPAMP GP R-R CMOS 10MHZ 8MSOP

In Stock:: 2239

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AD8606ARMZ-R2 Specifications

Package/Case:
8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Packaging:
Cut Tape (CT),Digi-Reel®
Series:
DigiTrim®
ProductStatus:
Obsolete
AmplifierType:
CMOS
NumberofCircuits:
2
OutputType:
Rail-to-Rail
SlewRate:
5V/µs
GainBandwidthProduct:
10 MHz
-3dbBandwidth:
-
Current-InputBias:
1 pA
Voltage-InputOffset:
80 µV
Current-Supply:
1mA (x2 Channels)
Current-Output/Channel:
80 mA
Voltage-SupplySpan(Min):
2.7 V
Voltage-SupplySpan(Max):
5.5 V
OperatingTemperature:
-40°C ~ 125°C
MountingType:
Surface Mount
