Analog Devices Inc. AD8513ARZ

Part No.:: AD8513ARZ

Manufacturer:: Analog Devices Inc.

Package:: 14-SOIC (0.154, 3.90mm Width)

Datasheet:: AD8513ARZ.pdf

Description:: IC OPAMP JFET 4 CIRCUIT 14SOIC

In Stock:: 7291

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AD8513ARZ Specifications

Package/Case:
14-SOIC (0.154, 3.90mm Width)
Packaging:
Tube
Series:
-
ProductStatus:
Active
AmplifierType:
J-FET
NumberofCircuits:
4
OutputType:
-
SlewRate:
20V/µs
GainBandwidthProduct:
8 MHz
-3dbBandwidth:
-
Current-InputBias:
25 pA
Voltage-InputOffset:
100 µV
Current-Supply:
2.2mA (x4 Channels)
Current-Output/Channel:
70 mA
Voltage-SupplySpan(Min):
10 V
Voltage-SupplySpan(Max):
30 V
OperatingTemperature:
-40°C ~ 125°C
MountingType:
Surface Mount
